4" Borehole Pumps
4SD Series
4SD series 4" stainless steel borehole pumps.
4SD deep well submersible pump is used to pump water from drilled deep wells, borehole wells, ponds, and lakes. Ideal for sprinkler lawn irrigation, elevated and cistern tanks filling, water fountains, industrial and farming water supply, and agricultural irrigation.
- Delivery
- Min: 0.3m3/h up to Max : 21m3/h
- Head
- Min: 8m up to Max: 220m
- Motor Size
- 4'' 220v- 1 Phase : 0.37kW up to 2.2kW; 380v - 3 Phase : 0.75kW up to 7.5kW
Choose a model
Specifications
- Speed
- 2850rpm
- Insulation class
- F
- Protection grade
- IP 68
- Maximum sand content
- 0.25%
- Minimum well diameter
- 4"
Applications
- Single-phase: 220v-240V/50Hz
- Three-phase: 380-415V/50Hz
- Pumps are designed by casing stressed NEMA dimension standards
- Curve tolerance according to ISO 9906
- Single phase motor unit
- Equip with start control box or digital auto-control box
Need help sizing a 4SD Series pump?
Send your flow and head and we will recommend the right model.
